VCBS SERIES

Vertical Cantilever Low Suction Pump

Recognized by the Chilean Government as a unique equipment in the world.

VCBS SERIES

Vertical Cantilever Low Suction Pump

Recognized by the Chilean Government as a unique equipment in the world.

These are single-stage vertical axis centrifugal pumps, 100% VS5 cantilever design with patented low suction design. Bearing body execution, with single volute casing, semi-open impeller and no mechanical seal, Heavy Duty performance with fully cantilevered shaft design without any support bushing.

This equipment operates in adverse working conditions and is affected by a large number of variables, both in the composition of the fluid and in the operating points and temperature variables, since they are located in the most important salt flats in Latin America.

Benefits

Saving water resources and reducing environmental impact, as our brine transfer equipment has the lowest water requirement for cleaning in the world.

Designed to operate in the heaviest working conditions.

The only one with maximum dewatering capacity that allows recovering valuable solutions, such as the final product in non-metallic mining processes.

The best solution in brine transfer at high altitude.

Capability

Capacity

@ 700 m3/hr

Head

@ 50 m.c.a.
0

Nominal Sizes

25 mm (1”) hasta 150 mm (6”)

Performance Curves

Performance Curves

Applications

  • Fresh Water Pumping

  • River, pond, dam Pumping.

  • PLS-ILS-Refining Water Pumping

  • Mine Dewatering

  • Truck Cleaning

  • Pool Cleaning

  • Residual Liquids

  • Wastewater Treatment and Industrial Applications, in general.

  • Water Recovery from Tailing Tanks

  • Firefighting Installations

  • Puddle Draining, Drainage systems.

  • Solution Transfer

  • Capture and Impulsion of Salt Water to process installations.

Fabrication process
in Chile

Lithium Processing

It begins with the extraction of lithium-rich brine from well fields drilled by VOGT Deep Well Pumps.

Through the VOGT Horizontal Pumps the brine is transferred to a series of pools that use solar radiation and wind for evaporation and concentration, along with a precipitation process to remove impurities.

The concentrated brine is transported to the lithium carbonate plant, where it precipitates, filters and dries the finished high quality lithium carbonate product using VOGT Transfer Pumps and Float Pumps.

Concentrated Brine

Concentrated Brine

Brine Transfer in Feed Troughs, Evaporation Troughs and Harvesting Troughs

Brine Transfer in Feed Troughs, Evaporation Troughs and Harvesting Troughs
