BB3 SERIES

SADB – DOUBLE SUCTION

Central support and resistant design.
Axial split, allows removal of the upper half of the casing.
Full compliance with API610 specifications.
Radial and axial balance is ensured by diffuser design and balancing piston or impeller arrangement.
Design flexibility for a wide range of fluids.
Low NPSH.

- Capacity: @ 204 m3/hr
- Head: @ 1500 M
- Pressures: @ 147 BAR
- Temperatures: @ 230°C
- Speeds: @ 3600 RPM

SAV / SAVD – SINGLE SUCTION

Full compliance with API610 specifications.
Double suction and first discharge impeller available for low NPSH conditions.
Near centerline support and axially split casing.
Opposing impeller balances axial thrust with balance drum.
Double volute construction minimizes radial thrust.

- Capacity: @ 4200 m3/hr
- Head: @ 1500 M
- Pressures: @ 200 BAR
- Temperatures: @ 230°C
- Speeds: @ 3600 RPM

DM – DOUBLE INLET

Double suction type to guarantee suction capacity.
Multi-stage design for great heights.
Double suction impeller.
Duplex, Super-Duplex available.
Axial thrust reduction.
Corrosion resistant material (in case of seawater service).

- Capacity: @ 15.000 m3/hr
- Head: @ 800 M
- Pressures: @ 80 BAR
- Temperatures: @ 120°C
- Speeds: @ 3600 RPM
