Water Hammer Phenomenon
[go to Blog]



















WATER HAMMER PONDS

One of the most common challenges in hydraulic systems is the «water hammer» phenomenon, caused by the sudden stop of pumping systems. This phenomenon can generate under/over pressures, affecting the integrity of the equipment and the efficiency of the system as a whole. In this context, we provide advanced solutions for protection against hydraulic transients, including analysis, design, manufacturing, assembly and commissioning in the field, preventing and mitigating the adverse effects of «water hammer». This comprehensive approach not only optimizes the performance of your pumping systems, but also mitigates the problems derived from continuous pump start-ups.

We guarantee an effective response to critical situations, protecting your installations from possible damage and optimizing the useful life of your equipment. By integrating these preventive solutions, we ensure that your pumping system operates continuously and efficiently, minimizing the risks associated with unwanted hydraulic phenomena.

Our experience and commitment to excellence can transform your operations, delivering a comprehensive approach that goes beyond simple equipment installation.

  • Max. Flow: @ 1000 l/s
  • Max. Pressure: @ 30 Bar
  • Temperature: -10 °C hasta 80 °C
  • Test Pressure: 1.5 P Máx.

Vertical Hydropneumatic Tanks with Membrane.

  • Models: HV 500-750-1000 liters.
  • PN 10
  • Membrane: EPDM
  • Thickness: 6 mm

APPLICATIONS

  • Protection of polyethylene lines, PVC, polypropylene irrigation.
  • Water hammer dampers.
  • Accumulators of water for emergencies.
  • Pressure stabilizers in drip irrigation systems, for emergency showers (flying systems).
  • In pump rooms in buildings, boosters or delivery rooms, stabilizing and regulating the flow, avoiding repetitive starts and stops.

Vertical Water Hammer Damper Tanks with Membrane.

  • Models: HVG 300-500-750-1000-1500-2000-2500-3000-3500-4000-5000 liters.
  • PN 10-16
  • Membrane: EPDM
  • Thickness: 6-8-10-12-14 mm

APPLICATIONS

  • Protection of PVC or PP supply lines in irrigation and pressure fluctuations.
  • Reduce to the maximum the stops due to damage to the impulsion equipment.
  • In sanitary ware to diminish the fluctuations by the extensive lines of impulsion.

Vertical and Horizontal Water Hammer Damper Tanks with Compressor or Nitrogen.

  • Models: HVG 500-750-1000-1500-2000-2500-3000-3500-4000-5000 liters.
  • PN 10-16
  • Thickness: 6-8-10-12-14 mm
  • Fluids: Drinking and Served Water.
  • Air injection: Compressor or Nitrogen.

APPLICATIONS

  • To avoid hydraulic transients.
  • In order not to interrupt the operation of the drive equipment, it does not require maintenance.

We have all the components and accessories necessary to develop these solutions:

  • Level indicator line
  • Manometer Line
  • Ball Valve
  • Fitting
  • Pressure transducer
  • Automatic relief valve
  • Box valve
  • Electric actuator for automatic valves
  • Power and control Panels
  • Pressurization equipment
